2.92mm Female (Jack) to 4 Hole 0.500" Square
| ID | D1 | D2 | L1 | L2 | Specs |
| D360P0403F01 | 1.67mm / 0.066" | 0.03mm / 0.012" | 1.4mm / 0.055" | 1.5mm / 0.059" |  PDF Spec |
| D360P0503F01 | 1.67mm / 0.066" | 0.03mm / 0.012" | 3mm / 0.118" | 1.5mm / 0.059" | PDF Spec |
2.92mm Female (Jack) to 4 Hole 0.375" Square
| ID | D1 | D2 | L1 | L2 | Specs |
| D360P0403F02 | 1.67mm / 0.066" | 0.03mm / 0.012" | 1.4mm / 0.055" | 1.5mm / 0.059" | PDF Spec |
| D360P0503F02 | 1.67mm / 0.066" | 0.03mm / 0.012" | 3mm / 0.118" | 1.5mm / 0.059" | PDF Spec |
2.92mm Female (Jack) to 2 Hole 0.625" Long
| ID | D1 | D2 | L1 | L2 | Specs |
| D360P0403F04 | 1.67mm / 0.066" | 0.03mm / 0.012" | 1.4mm / 0.055" | 1.5mm / 0.059" | PDF Spec |
| D360P0503F04 | 1.67mm / 0.066" | 0.03mm / 0.012" | 3mm / 0.118" | 1.5mm / 0.059" | PDF Spec |
2.92mm Female (Jack) to 2 Hole 0.550" Long
| ID | D1 | D2 | L1 | L2 | Specs |
| D360P0403F05 | 1.67mm / 0.066" | 0.03mm / 0.012" | 1.4mm / 0.055" | 1.5mm / 0.059" | PDF Spec |
| D360P0503F05 | 1.67mm / 0.066" | 0.03mm / 0.012" | 3mm / 0.118" | 1.5mm / 0.059" | PDF Spec |
2.92mm Female (Jack) to 2 Hole 0.500" Long
| ID | D1 | D2 | L1 | L2 | Specs |
| D360P0403F06 | 1.67mm / 0.066" | 0.03mm / 0.012" | 1.4mm / 0.055" | 1.5mm / 0.059" | PDF Spec |
| D360P0503F06 | 1.67mm / 0.066" | 0.03mm / 0.012" | 3mm / 0.118" | 1.5mm / 0.059" | PDF Spec |
2.92mm Female (Jack) to 2 Hole 0.500" Long
| ID | D1 | D2 | L1 | L2 | Specs |
| D360P0403F07 | 1.67mm / 0.066" | 0.03mm / 0.012" | 1.4mm / 0.055" | 1.5mm / 0.059" | PDF Spec |
| D360P0503F07 | 1.67mm / 0.066" | 0.03mm / 0.012" | 3mm / 0.118" | 1.5mm / 0.059" | PDF Spec |
-
